Рентгеновская трубка служит источником рентгеновского излучения, предназначена для рентген аппаратов, содержащих рентгеновские трубки.
Рентгеновские трубки применяют в рентгеновском структурном анализе, рентгенодиагностике, рентгенотерапии, рентгеновской микроскопии и микрорентгенографии.
- Focal spots 0.6-22 kW and 1.2-54 kW
- 150 kV nominal voltage
- 12º target angle
- 230 kHU anode heat storage.
- Tube Insert Type: RAY –12
- Part number: Depending on version
- Application: OEM and Field Service
- Nominal voltage, IEC 60 613: 150 kV
- Maximum voltage in fluoroscopy: 110 kV
- Nominal focal spot value, IEC 60 336: 0.6; 1.2
- Nominal power 60 Hz, IEC 60 613: 22 kW; 54 kW
- Thermal anode reference power, 300 W
- Filament heating: AC
max. current: 4.6 A; 5.5 A
max. voltage: ? 7 VAC; ? 9 VAC
- Target angle, IEC 60 788: 12º, 74 mm (3")
- Anode material: Rhenium-tungsten, molybdenum (RTM)
- Anode heat storage capacity, IEC 60 613:
170,000 J = 230,000 HU
- Maximum anode heat dissipation, IEC 60 613: 67,500 J/min = 91,125 HU/min
- Anode drive frequency during exposure:
50 / 60 Hz (25 Hz)
- Anode boosting time (starter type): ? 1.2s (single-phase)
- Heat storage capacity of THA, IEC 60 613: 1.0 MJ = 1.35 MHU
- Max. continuous heat dissipation of THA, IEC 60 613: 275 W / 450 W (with / without fan)
- Leakage radiation, IEC 60 601-1-3:
- Total filtration (Al equivalent), IEC 60 601-1-3: 2.5 mmAl / 80 kV
- Weight: ? 18 kg.
